PRO-AM 3.0 - Structural furler - Max forestay dia: 7 mm

Part #PROAM3.0V2

Description

PRO-AM is a structural furler for 5 to 9.5 meters boats designed for “all or nothing” sailing (with sails fully unfurled). The sail is hoisted and hauled thanks to a second swivel called a “halyard swivel”. PRO AM also allows you to strike the sail for wintering, maintenance or just for storage after use.

Technical description

Why choose a PRO-AM furler?
• The ideal system for Day Boats and Sports Boats
• Light and easy to handle
• Sail can be hoisted and lowered
• Possibility to remove easily the halyard swivel only.
• Quick fitting and removal for trailer boats
• Profurl system: maintenance-free components mounted in a sealed grease bath.
• Three-year Profurl worldwide limited warranty.

Performance
S-GRIP: the special groove design, allowing for deformation of the line, ensures:
• better line grip, even when wet!
• easier furling
• minimum line wear

OPTIMAL FURLING: the optimal spool diameter provides ideal torque, which makes furling easier and reduces effort XTRA-LIGHT SYSTEMS: the size and weight of each component (spool, swivel, and terminals) have been optimised to improve sailing performance and ensure easier handling of the systems

Safety
SAFE SYSTEM: enables you to stop the running of the furling line during deployment of sail and thus
• prevent accidents or damage caused by a free running line.
• manoeuvre more quickly and easily
• prevent excessive wear of the line

Components

1 spool, 1 head swivel 1 halyard swivel and soft sahckles, 2 stainless steel toggles

Technical information

  • Sailing program Cruising, racing
  • Structural system Yes
  • Partial furling of the sail No
  • Max forestay dia (mm) 7
  • Ratchet No
  • Working load 2000
  • Halyard swivel working load (kg) 600
  • Spool diameter (mm) 150
  • Pin diameter (mm) 12
  • Furling line diameter (mm) 8
  • Warranty 3 years

Documentation and CAD Files

CAD files
  • PDF
  • DXF

CAD files
